Bharat Industries specializes in tailor-made Welded Wire Mesh panels
That offer exceptional stability and durability. Crafted from premium materials and manufactured using advanced industry-leading techniques, our mesh panels ensure superior quality and longevity.
We provide customized solutions in GI (Galvanized), MS (Mild Steel), and SS Stainless Steel Welded Wire Mesh , catering to specific client requirements with precision and reliability.
We offer Welded Wire Mesh of superior quality, designed for durability and strength. It is widely used in construction, agriculture, fencing, industrial reinforcement, and security applications.
Welded Mesh are Available in various sizes and specifications, we ensure it meets diverse customer needs. Our products are offered at affordable prices, making them a cost-effective solution without compromising on quality.
Our Applications
Industrial Fencing
Highway Fencing
Railway
Airport
Institutions
Housing
APPROX WEIGHT PER SQ. FEET
| SR.NO. | MESH SIZE MM | WIRE DIA MM | WIDTH & LENGTH | APPROX WEIGHT |
|---|---|---|---|---|
| 1 | 15MM X 15MM | 1.40MM | 3X50 | 18-19 |
| 2 | 15MM X 15MM | 1.40MM | 4X50 | 24-25 |
| 3 | 15MM X 15MM | 1.40MM | 5X50 | 29-30 |
| 4 | 25MM X 25MM | 2.45MM | 3X50 | 38-39 |
| 5 | 25MM X 25MM | 2.45MM | 4X50 | 49-50 |
| 6 | 25MM X 25MM | 2.75MM | 3X50 | 48-49 |
| 7 | 25MM X 25MM | 2.75MM | 4X50 | 64-65 |
| 8 | 25MM X 25MM | 2.75MM | 5X50 | 80-81 |
| 9 | 30MM X 30MM | 2.30MM | 3X50 | 22-23 |
| 10 | 30MM X 30MM | 2.30MM | 4X50 | 30-31 |
| 11 | 30MM X 30MM | 2.30MM | 5X50 | 38-39 |
| 12 | 30MM X 30MM | 2.75MM | 3X50 | 37-38 |
| 13 | 30MM X 30MM | 2.75MM | 4X50 | 49-50 |
| 14 | 30MM X 30MM | 2.75MM | 5X50 | 59-60 |
| 15 | 50MM X 50MM | 2.20MM | 4X100 | 43-44 |
| 16 | 50MM X 50MM | 2.20MM | 5X100 | 54-55 |
| 17 | 50MM X 50MM | 2.90MM | 4X100 | 71-72 |
| 18 | 50MM X 50MM | 2.90MM | 5X100 | 92-93 |
